INFO: The Coil Spring Thread

 Post Reply Post Reply Page  <12345 20>
Author
Message
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 27-August-2010 at 3:33PM
Originally posted by Eliteman76 Eliteman76 wrote:

I am going to have my fronts as a winter project, and want to check brand and model you used.


This is what I'm going with. Already bought!!

MOOG Part # 80090
1998 - 2002 Crown Vic
1998 - 2002 Mercury Grand Marq
Inside DiaBar DiaInstall HeightLoad rate (lbs)Spring Rate (Lbs/in.)Free HeightEnd Type
4.04                           0.781                  11.75                    2034                      710                         14.38                     One Square End and 1 Tangential End
Jim


Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 30-August-2010 at 5:31PM
Carl...look up here:
http://www.speedwaymotors.com/Street-Stock-Replacement-Front-Springs,166.html
Stock replacement front spring. 12" tall with no spacer needed. Fits most street stocks with 5-1/2" springs. Ground flat on one end. Available in the following rates: 925, 1000, 1150, 1250, 1350 and 1450 lb.

I need to dig out my old Speedway Motors oval catalog, but if you are going dirt racing, just stick in a superstock spring of around 1000-1400 pounds. You can also pick up rear springs there as well in Lincoln, NE and get them shipped cheap.
WARNING: these springs not meant for street driving kids. Not unless you want the fillings rattled out of your teeth.

Jim- That spring, I'm curious, but you have a 429...I am running a 351c.
I know Gary in his killer red '73 I think stuck CV springs in, but I don't recall. I just need to lift my nose back up a little. My springs are a tick too short I think.

Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
Psquare75 View Drop Down
Admin Group
Admin Group

Member of the Stroker Club

Joined: 26-November-2005
Location: United States
Status: Offline
Points: 4591
Post Options Post Options   Thanks (0) Thanks(0)   Quote Psquare75 Quote  Post ReplyReply Direct Link To This Post Posted: 31-August-2010 at 2:28AM
Originally posted by cowboyupdjcarl cowboyupdjcarl wrote:

Don't throw away your old springs!
I may be interested in buying some so I have different rates/height for my Dirt Race Car.

I've got a set of 302 springs from my LTD II I parted. Interested?
Paul
77 XR7 460/C6/3.00:1 *SOLD*
78 XR7 523/C6/3.5:1
79 F100 460/TKO500/3.25:1
'I also have some left over potatoes-I understand you can generate electricity from them'- Foote500
Back to Top
Regul8r View Drop Down
Admin Group
Admin Group
Avatar
Moderator

Joined: 26-December-2007
Location: Sarasota FL
Status: Offline
Points: 6624
Post Options Post Options   Thanks (0) Thanks(0)   Quote Regul8r Quote  Post ReplyReply Direct Link To This Post Posted: 31-August-2010 at 7:37AM
probably to light, but thanks anyway.

72 Gran Torino with a 351W barreling 80 mph into a corner I THINK I am going to need a pretty stiff spring.
Andy, I am already looking at Speedway. Thanks
Carl Corey (Moderator/Event Coordinator) Contact ANYTIME!
1976 Ford Elite "Lola Mae"
97 Suzuki Intruder 1400
US Army Retired
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 31-August-2010 at 10:01AM
Originally posted by Eliteman76 Eliteman76 wrote:

Jim- That spring, I'm curious, but you have a 429...I am running a 351c.
I know Gary in his killer red '73 I think stuck CV springs in, but I don't recall. I just need to lift my nose back up a little. My springs are a tick too short I think.

I can't say for sure if they will lift it for you like you want it too, but it is a stiffer spring and I don't think the dif between the 429 and 351 would make any significant difference.
Jim


Back to Top
Torinogts73c View Drop Down
Senior Member
Senior Member
Avatar

Joined: 14-February-2004
Location: Tucson Arizona
Status: Offline
Points: 1034
Post Options Post Options   Thanks (0) Thanks(0)   Quote Torinogts73c Quote  Post ReplyReply Direct Link To This Post Posted: 01-September-2010 at 4:37PM
Yes I installed CV Police car springs in my GTS and ride height is perfect  I think part#D9AZ-5310-W was the ones. have to check my records.
Gary 73 Gran Torino Sport 351CJ,17 Mustang Ecoboost,15 Jeep Grand Cherokee LTD, Ford Ranger parts hauler


"Never complain Never explain" Henry Ford
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 01-September-2010 at 4:51PM
CV Police Springs
MOOG Part # 80090
Jim


Back to Top
Torinogts73c View Drop Down
Senior Member
Senior Member
Avatar

Joined: 14-February-2004
Location: Tucson Arizona
Status: Offline
Points: 1034
Post Options Post Options   Thanks (0) Thanks(0)   Quote Torinogts73c Quote  Post ReplyReply Direct Link To This Post Posted: 01-September-2010 at 5:28PM
I checked my notes on the specs of my springs almost identical to the ones you have from Moog!! I thought they looked similar. good find!
Gary 73 Gran Torino Sport 351CJ,17 Mustang Ecoboost,15 Jeep Grand Cherokee LTD, Ford Ranger parts hauler


"Never complain Never explain" Henry Ford
Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 02-September-2010 at 6:01AM
Gary-
What do you show for a cost on the CV springs from Ford?
Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
dvldog2513 View Drop Down
Member
Member
Avatar

Joined: 18-July-2010
Location: Lexington S.C.
Status: Offline
Points: 135
Post Options Post Options   Thanks (0) Thanks(0)   Quote dvldog2513 Quote  Post ReplyReply Direct Link To This Post Posted: 02-September-2010 at 7:04AM
Before you pick out a set of stock coil springs for the dirt track .Check the rules for the class you are going to be racing in because from the rates i have seen on this post they are to lite .You need to know what the weight of the car if the track is banked or flat size of the track 3\8 mi,4\10mi. I've been racing dirt track on and off since 1993 and i'm still learning.I race a 3400 pound car 1200# r\f 1000#l\f 225# r\r 275#l\r 4\10 mi banked track 2nd gear auto 4.10 rear end . I'm running afco racing springs. Check out Day motorsports they deal in dirt track parts .
Back to Top
Torinogts73c View Drop Down
Senior Member
Senior Member
Avatar

Joined: 14-February-2004
Location: Tucson Arizona
Status: Offline
Points: 1034
Post Options Post Options   Thanks (0) Thanks(0)   Quote Torinogts73c Quote  Post ReplyReply Direct Link To This Post Posted: 02-September-2010 at 4:14PM
Originally posted by Eliteman76 Eliteman76 wrote:

Gary-
What do you show for a cost on the CV springs from Ford?
Well guess what? Ford has stopped making them!! Go figure!
Gary 73 Gran Torino Sport 351CJ,17 Mustang Ecoboost,15 Jeep Grand Cherokee LTD, Ford Ranger parts hauler


"Never complain Never explain" Henry Ford
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 03-September-2010 at 10:31AM
Originally posted by Torinogts73c Torinogts73c wrote:

Originally posted by Eliteman76 Eliteman76 wrote:

Gary-
What do you show for a cost on the CV springs from Ford?
Well guess what? Ford has stopped making them!! Go figure!

That's why I bought these....

CV Police Springs
MOOG Part # 80090

Amazon has the cheapest price. Basically the same spring as factory.
Jim


Back to Top
Torinogts73c View Drop Down
Senior Member
Senior Member
Avatar

Joined: 14-February-2004
Location: Tucson Arizona
Status: Offline
Points: 1034
Post Options Post Options   Thanks (0) Thanks(0)   Quote Torinogts73c Quote  Post ReplyReply Direct Link To This Post Posted: 04-September-2010 at 1:11AM
He's right the specs are the same!
Gary 73 Gran Torino Sport 351CJ,17 Mustang Ecoboost,15 Jeep Grand Cherokee LTD, Ford Ranger parts hauler


"Never complain Never explain" Henry Ford
Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 04-September-2010 at 5:55AM
Jim, never used Amazon, but had a buddy show me them when I was looking for my Xbox live membership and how cheap you could find it on there.
Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 04-September-2010 at 10:33AM
Free shipping too!
Jim


Back to Top
moose0211 View Drop Down
Senior Member
Senior Member
Avatar

Joined: 23-September-2009
Location: Baltimore
Status: Offline
Points: 456
Post Options Post Options   Thanks (0) Thanks(0)   Quote moose0211 Quote  Post ReplyReply Direct Link To This Post Posted: 05-September-2010 at 3:38AM
So, CVPI springs MOOG Part # 80090 coils will work with no modifications and give the best ride height. Gary, did you cut any coils off of it?

Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 05-September-2010 at 7:00PM
OK, 80090 I find on Ebay, listed as rears. What about the fronts??
Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 06-September-2010 at 5:35AM
Originally posted by Eliteman76 Eliteman76 wrote:

OK, 80090 I find on Ebay, listed as rears. What about the fronts??

MOOG 80090 are front springs not rear. Get 'em from Amazon. Save $$$$
Jim


Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 06-September-2010 at 5:51AM
Got to wait a bit, if you pick up those wheels off me, THEN I get the springs Wink
Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 06-September-2010 at 6:25AM
Originally posted by Eliteman76 Eliteman76 wrote:

Got to wait a bit, if you pick up those wheels off me, THEN I get the springs Wink

LOL sounds like a plan. I will call you when I get a chance. Let me know a good time.
Jim


Back to Top
Eliteman76 View Drop Down
Admin Group
Admin Group


Joined: 20-March-2006
Location: Nebraska, USA
Status: Offline
Points: 5044
Post Options Post Options   Thanks (0) Thanks(0)   Quote Eliteman76 Quote  Post ReplyReply Direct Link To This Post Posted: 06-September-2010 at 6:38AM
My phone is charging right now, but I am actually getting off the imac so I can go outside and start digging out crap from one of the sheds. Wacko
Andrew:GTS.ORG admin, '72 Q code 5 speed Restomod
Pondering: #99Problems
Back to Top
Psquare75 View Drop Down
Admin Group
Admin Group

Member of the Stroker Club

Joined: 26-November-2005
Location: United States
Status: Offline
Points: 4591
Post Options Post Options   Thanks (0) Thanks(0)   Quote Psquare75 Quote  Post ReplyReply Direct Link To This Post Posted: 06-September-2010 at 7:32AM
Originally posted by moose0211 moose0211 wrote:

So, CVPI springs MOOG Part # 80090 coils will work with no modifications and give the best ride height.


With what engine/combo and what height?
Paul
77 XR7 460/C6/3.00:1 *SOLD*
78 XR7 523/C6/3.5:1
79 F100 460/TKO500/3.25:1
'I also have some left over potatoes-I understand you can generate electricity from them'- Foote500
Back to Top
Torinogts73c View Drop Down
Senior Member
Senior Member
Avatar

Joined: 14-February-2004
Location: Tucson Arizona
Status: Offline
Points: 1034
Post Options Post Options   Thanks (0) Thanks(0)   Quote Torinogts73c Quote  Post ReplyReply Direct Link To This Post Posted: 07-September-2010 at 1:50PM
I didn't cut any coils they are stock CVPI springs. 351CJ, C-6, A/C , Comp. suspension
Gary 73 Gran Torino Sport 351CJ,17 Mustang Ecoboost,15 Jeep Grand Cherokee LTD, Ford Ranger parts hauler


"Never complain Never explain" Henry Ford
Back to Top
GA Army Vet View Drop Down
Member
Member


Joined: 24-October-2010
Location: 30525 GA
Status: Offline
Points: 126
Post Options Post Options   Thanks (0) Thanks(0)   Quote GA Army Vet Quote  Post ReplyReply Direct Link To This Post Posted: 22-November-2010 at 5:38PM
Swaping the 1973 GTS 351c to a 460, A/C and P/S nothing stripped, live in the mountains and want to have a good handeling car. NOT A SPORTS CAR, but something that wont roll the car to bad. I know its an old car, but looking to hold the engine as well as slow her roll.

Please dont reply with all the number as I read this post twice and didnt get the numbers. I just need a pt # someone else used. Also I have a boken back so I am not looking to have a stiff ride. I do like it soft. I am picking up a rearsway bar and front upgrade. This guy that lives in my housing area told me he has coilover shocks that will fit, and wants to sell them he said they would stiffen up things but not to bad... Any info on this
1973 GTS-351c C6 28sp axle 2.73gears (looking to change)



2004 electric wheelchair super fast!



Disabled Iraq Vet, IED boke my back and severed my nerves into my legs I can walk but it hurts bad.
Back to Top
Regul8r View Drop Down
Admin Group
Admin Group
Avatar
Moderator

Joined: 26-December-2007
Location: Sarasota FL
Status: Offline
Points: 6624
Post Options Post Options   Thanks (0) Thanks(0)   Quote Regul8r Quote  Post ReplyReply Direct Link To This Post Posted: 05-December-2010 at 4:50PM
All this talk on the front springs...

What about the REARS...

What MOOG Cargo Coils is anyone running?
More info I found in the MOOG book at O'Reilly's and on the phone with Andy
REAR SPRINGS
    Free HT Install HT Rate/Weight Price
72-79 ALL CC801 14.5 9.75 192/870 95
Wagon CC803 14.19 9.75 305/1330
75 torino CC807 15.25 ?? 180/1000 114.99
73-76 Wagon CC811   10.5 315/1350 81.99
79 and newer ALL CC819   12.69 200/780 95

Looks like CC801will keep stock height, 803 will be ROCK HARD, 807 might raise the rear a little but be a decent ride, the 811 is rock hard and higher,819 is WAY taller but softer ride

So I am getting a set of 801's for the yellow car that will have the wheels tucked inside the wheel lip, but probably need the 807 for the 3.5BS slots on "Ol' Brown" to give it a little more height and stiff to make sure it doesn't rub on top of the tire.
Carl Corey (Moderator/Event Coordinator) Contact ANYTIME!
1976 Ford Elite "Lola Mae"
97 Suzuki Intruder 1400
US Army Retired
Back to Top
73GTS View Drop Down
Senior Member
Senior Member
Avatar

Joined: 22-September-2008
Location: Cleveland, Ohio
Status: Offline
Points: 945
Post Options Post Options   Thanks (0) Thanks(0)   Quote 73GTS Quote  Post ReplyReply Direct Link To This Post Posted: 06-December-2010 at 1:23PM
I bought the CC811's. Hoping they'll plant the big 325/50R15 Mickey Thompson E/T. Drag Radial's Wink
Jim


Back to Top
Regul8r View Drop Down
Admin Group
Admin Group
Avatar
Moderator

Joined: 26-December-2007
Location: Sarasota FL
Status: Offline
Points: 6624
Post Options Post Options   Thanks (0) Thanks(0)   Quote Regul8r Quote  Post ReplyReply Direct Link To This Post Posted: 06-December-2010 at 3:39PM
Originally posted by 73GTS 73GTS wrote:

I bought the CC811's. Hoping they'll plant the big 325/50R15 Mickey Thompson E/T. Drag Radial's Wink
WOW really?
that is gonna be one hell of a stiff ride!!!
Pic of the car with them installed?
Carl Corey (Moderator/Event Coordinator) Contact ANYTIME!
1976 Ford Elite "Lola Mae"
97 Suzuki Intruder 1400
US Army Retired
Back to Top
Blueoval76 View Drop Down
Senior Member
Senior Member
Avatar
Member of the Stroker Club

Joined: 20-February-2010
Location: Sussex WI
Status: Offline
Points: 698
Post Options Post Options   Thanks (0) Thanks(0)   Quote Blueoval76 Quote  Post ReplyReply Direct Link To This Post Posted: 06-December-2010 at 4:11PM
I have the CC801's on my car. They can be seen a few pages back. There was no difference in height from the springs that were on the car when I got it. As far as ride they are fine to me as far as bumps go. I cant tell cornering because I have big MT Sportsmans that sway a ton and a 4.56 locker that I prefer to take it easy on. Smile
68 Galaxie Wagon 390/auto/2.70
03 Bonneville some mods
Back to Top
Regul8r View Drop Down
Admin Group
Admin Group
Avatar
Moderator

Joined: 26-December-2007
Location: Sarasota FL
Status: Offline
Points: 6624
Post Options Post Options   Thanks (0) Thanks(0)   Quote Regul8r Quote  Post ReplyReply Direct Link To This Post Posted: 06-December-2010 at 4:53PM
Originally posted by Blueoval76 Blueoval76 wrote:

Ok so here is a few pics of the front suspension and I still dont see a difference except that one coil is bunched up at the bottom vs one being with normal gap. Maybe its just me! Lol!

New springs...


Old springs...


Upper A arms with old springs...

I just noticed you have 2 different Upper A-Arms!!
The passenger side is the HD/PI one it has screw in upper control arm bushings.
The driver side is the standard press-in upper control arm bushings.
That should not affect ride height from side to side but it could cause issues with other front end geometry.
Carl Corey (Moderator/Event Coordinator) Contact ANYTIME!
1976 Ford Elite "Lola Mae"
97 Suzuki Intruder 1400
US Army Retired
Back to Top
Blueoval76 View Drop Down
Senior Member
Senior Member
Avatar
Member of the Stroker Club

Joined: 20-February-2010
Location: Sussex WI
Status: Offline
Points: 698
Post Options Post Options   Thanks (0) Thanks(0)   Quote Blueoval76 Quote  Post ReplyReply Direct Link To This Post Posted: 06-December-2010 at 5:01PM
Lmao!! So you dont think that would make the pass. side sit any higher at all or anything? I don't know for sure as it might be all in the rear where the chassis was set up. I think the only way to find out for sure is to get it to a chassis shop to see if they can figure it out. Thanks though I am glad to know that It is a PI A-arm as I knew there was something different about that arm. I think its safe to assume that the lower is also from the PI and also maybe the spindle.
68 Galaxie Wagon 390/auto/2.70
03 Bonneville some mods
Back to Top
 Post Reply Post Reply Page  <12345 20>

Forum Jump Forum Permissions View Drop Down

Forum Software by Web Wiz Forums® version 12.06
Copyright ©2001-2023 Web Wiz Ltd.

This page was generated in 0.188 seconds.
